Starlight Low-Light Wide Dynamic Range IMX662 1080P 60fps 90° MIPI Camera Module
The Haozhou IMX662-AAQR-C is a 6.45mm CMOS active-pixel sensor MIPI camera module, featuring a square array with 2.4 million effective pixels. This module employs a triple-supply design—incorporating separate power supplies for analog, digital, and interface circuits—thereby enabling low-power operation. Thanks to its RGB primary-color mosaic filter, the sensor exhibits exceptional characteristics, including high sensitivity, low dark current, and smear-free performance. It features a built-in electronic shutter that supports variable charge integration times as well as multiple readout modes; in 10-bit mode, it achieves a maximum frame rate of 90 fps. As a Sinoseen sensor specifically engineered for the security surveillance camera sector, it is ideally suited for High Dynamic Range (HDR) applications.
High-Speed 90 FPS @ 1080P: Delivers exceptionally smooth and clear video, ideal for capturing fast-moving objects without motion blur.
Advanced IMX662 Sensor: Ensures high image quality with excellent sensitivity and dynamic range, providing reliable performance for demanding vision tasks.
Compact Design: The small 32x20mm form factor allows for easy integration into various projects and enclosures.
Standard MIPI Interface: Includes FPC flexible cable for direct connection to your Raspberry Pi's MIPI CSI port.
Customizable Lens Options: Multiple focal lengths available to suit different application needs.
Security & Surveillance
Industrial Machine Vision
Smart Retail & IoT
Teleconferencing & Live Streaming
|
|
1080p 90fps Sony IMX662 Low Light Cmos Camera Module 2MP MIPI Interface Images
|
